VCMA-20-PRO Series Condensate Pump
VCMA-20-PRO Series Condensate Pump
Condensation build-up in air conditioning equipment can wreak havoc on your HVAC system. Little Giant's VCMA-20-PRO Series condensate pump provides a high-capacity option for the automatic collection and removal of condensate from air conditioning, refrigeration and dehumidification equipment when gravity drainage is not possible. Its slim footprint makes this condensate pump the optimal choice for tight spaces.
Features & Benefits
- 1/30 hp high-performance motor
- ABS tank, motor cover, and volute
- Stainless steel motor shaft
- Fully automatic start/stop and safety switch operations
- Thermally protected fan-cooled motor to prevent overheating and possible motor damage
- "Anti-sweat" tank sleeve included on select models and available separately for all others
- CSA certified to US and Canada standards
Overview
With the slimmest footprint of all Little Giant condensate pumps, the VCMA-PRO Series of condensation pumps offers the largest installation flexibility. The vertical-type pump features a 3/8" O.D. barbed with 1/4-turn quick release locking discharge adapter with built-in check valve. Three 1-1/8" diameter inlet openings (two fitted with removal cap plugs) allow the pump to be used with multiple types of equipment, including air conditioners and furnace systems.
Specifications
| Capacity | 84 gph @ 1' / 115 V 78 gph @ 1' / 230 V |
| Shut Off | 21' (6.4 m) / 115 V 19' (5.7 m) / 230 V |
| Max. Liquid Temp. | 140 °F (60 °C) |
| Discharge | 3/8" barbed (9.5 mm) |
| Impeller | Glass-filled Polypropylene |
| Electrical | 115 V, 60 Hz, 1.5 A 230 V, 50/60 Hz, 0.57/0.6 A |
| Operation | Automatic |
Performance
| Head | GPH (LPH) / 115 V | GPH (LPH) / 230 V |
| 1' | 84 (318.4) | 78 (295.6) |
| 5' | 75 (284.3) | 67 (253.9) |
| 10' | 60 (227.4) | 51 (193.3) |
| 15' | 42 (159.2) | 29 109.9 |
| 20' | 10 (37.9) | 0 (0) |
Order Information
VCMA-20-PRO Series Condensate Pump
| Item | Model | Volts | Shut-Off | Safety Switch | Tubing Included |
|---|---|---|---|---|---|
| 554620 | VCMA-20UL-PRO | 115 VAC | 21 ft | No | No |
| 554630 | VCMA-20ULS-PRO | 115 VAC | 21 ft | Yes | No |
| 554650 | VCMA-20ULST-PRO | 115 VAC | 21 ft | Yes | Yes |
| 554621 | VCMA-20UL-PRO | 230 VAC | 20 ft | No | No |
| 554631 | VCMA-20ULS-PRO | 230 VAC | 20 ft | Yes | No |
| 554651 | VCMA-20ULST-PRO | 230 VAC | 20 ft | Yes | Yes |
VCMA-20-PRO Series with Anti-Sweat Sleeve
| Item | Model | Volts | Shut-Off | Safety Switch | Tubing Included |
|---|---|---|---|---|---|
| 554642 | VCMA-20ULS-C-PRO | 115 VAC | 21 ft | Yes | No |
